Sample usage: Here is a pair of classes in which a group * of worker threads use two countdown latches: *

* *
 {@code
 * class Driver { // ...
 *   void main() throws InterruptedException {
 *     CountDownLatch startSignal = new CountDownLatch(1);
 *     CountDownLatch doneSignal = new CountDownLatch(N);
 *
 *     for (int i = 0; i < N; ++i) // create and start threads
 *       new Thread(new Worker(startSignal, doneSignal)).start();
 *
 *     doSomethingElse();            // don't let run yet
 *     startSignal.countDown();      // let all threads proceed
 *     doSomethingElse();
 *     doneSignal.await();           // wait for all to finish
 *   }
 * }
 *
 * class Worker implements Runnable {
 *   private final CountDownLatch startSignal;
 *   private final CountDownLatch doneSignal;
 *   Worker(CountDownLatch startSignal, CountDownLatch doneSignal) {
 *     this.startSignal = startSignal;
 *     this.doneSignal = doneSignal;
 *   }
 *   public void run() {
 *     try {
 *       startSignal.await();
 *       doWork();
 *       doneSignal.countDown();
 *     } catch (InterruptedException ex) {} // return;
 *   }
 *
 *   void doWork() { ... }
 * }}
``` # 线程创建 线程创建通常有3中方法: - 继承 Thread 类 - 实现 Runnable 接口 - 实现 Callable 接口 实现 Runnable 接口来创建一个线程: ``` java public class MyThread extends Thread { public static void main(String[] args) { Thread t1 = new MyThread(); t1.start(); Thread t2 = new Thread(new MyThread2()); t2.start(); Callable call = new MyCallable(); FutureTask task = new FutureTask(call); Thread t3 = new Thread(task); t3.start(); } @Override public void run() { System.out.println("线程运行中---------extends"); } static class MyThread2 implements Runnable{ @Override public void run() { System.out.println("线程运行中------runnable"); } } static class MyCallable implements Callable{ @Override public String call() throws Exception { System.out.println("线程运行中------callable"); return "call over!"; } } } ``` # 线程间协作 ## join 在线程中调用另一个线程的 join() 方法,会将当前线程挂起,而不是忙等待,直到目标线程结束。 对于以下代码,虽然 b 线程先启动,但是因为在 b 线程中调用了 a 线程的 join() 方法,b 线程会等待 a 线程结束才继续执行,因此最后能够保证 a 线程的输出先于 b 线程的输出。 ``` java public class JoinExample { public static void main(String[] args) { JoinExample example = new JoinExample(); example.test(); } private class A extends Thread { @Override public void run() { System.out.println("A"); } } private class B extends Thread { private A a; B(A a) { this.a = a; } @Override public void run() { try { a.join(); } catch (InterruptedException e) { e.printStackTrace(); } System.out.println("B"); } } public void test() { A a = new A(); B b = new B(a); b.start(); a.start(); } } ``` ## wait wait 方法会使得当前线程进入等待状态,使用 wait() 挂起期间,线程会释放锁。这是因为,如果没有释放锁,那么其它线程就无法进入对象的同步方法或者同步控制块中,那么就无法执行 notify() 或者 notifyAll() 来唤醒挂起的线程,造成死锁。 wait() 和 sleep() 的区别 - wait() 是 Object 的方法,而 sleep() 是 Thread 的静态方法; - wait() 会释放锁,sleep() 不会。 ## interrupt 线程中断的方法有两种: 1. 使用 interrupted()来作为线程循环执行的判断条件 ``` java public class InterruptExample { private static class MyThread2 extends Thread { @Override public void run() { while (!interrupted()) { // .. } System.out.println("Thread end"); } } } ``` 2. 使用InterruptedException 通过调用一个线程的 interrupt() 来中断该线程,如果该线程处于阻塞、限期等待或者无限期等待状态,那么就会抛出 InterruptedException,从而提前结束该线程。但是不能中断 I/O 阻塞和 synchronized 锁阻塞 对于以下代码,在 main() 中启动一个线程之后再中断它,由于线程中调用了 Thread.sleep() 方法,因此会抛出一个 InterruptedException,从而提前结束线程,不执行之后的语句。 ``` java public class InterruptExample { private static class MyThread1 extends Thread { @Override public void run() { try { Thread.sleep(2000); System.out.println("Thread run"); } catch (InterruptedException e) { e.printStackTrace(); } } } } public static void main(String[] args) throws InterruptedException { Thread thread1 = new MyThread1(); thread1.start(); thread1.interrupt(); System.out.println("Main run"); } ``` ## Condition java.util.concurrent 类库中提供了 Condition 类来实现线程之间的协调,可以在 Condition 上调用 await() 方法使线程等待,其它线程调用 signal() 或 signalAll() 方法唤醒等待的线程。相比于 wait() 这种等待方式,await() 可以指定等待的条件,因此更加灵活。 ``` java public class AwaitSignalExample { private Lock lock = new ReentrantLock(); private Condition condition = lock.newCondition(); public void before() { lock.lock(); try { System.out.println("before"); condition.signalAll(); } finally { lock.unlock(); } } public void after() { lock.lock(); try { condition.await(); System.out.println("after"); } catch (InterruptedException e) { e.printStackTrace(); } finally { lock.unlock(); } } } ``` # Executor 框架 Executor 框架主要由3大部分组成,如下: ![](img/TIM截图20180801171519.jpg) - 任务 被执行的任务需要实现 Runnable 或者 Callable接口 - 任务的执行 任务执行的核心接口 Executor, 以及继承自 Executor 的 ExecutorService 接口。 Executor 框架有两个关键类实现了 ExecutorService 接口(ThreadPoolExecutor 和 ScheduledThreadPoolExecutor) - 异步计算的结果 ![](img/TIM截图20180801172104.jpg) Future 接口和 FutureTask 类 ## Executor 主要的类和接口 类和接口 | 说明 --- | --- Executor | 一个接口,其定义了一个接收Runnable对象的方法executor,其方法签名为executor(Runnable command), Executor 框架的基础,它将任务的提交和任务的执行分离开来 ExecutorService | 是一个比Executor使用更广泛的子类接口,其提供了生命周期管理的方法,以及可跟踪一个或多个异步任务执行状况返回Future的方法 AbstractExecutorService | ExecutorService执行方法的默认实现 ThreadPoolExecutor | 线程池的核心实现类,用来执行被提交的任务。通过调用Executors以下静态工厂方法来创建线程池并返回一个ExecutorService对象 ScheduledExecutorService | 一个可定时调度任务的接口 ScheduledThreadPoolExecutor | ScheduledExecutorService 的实现类, 可以在给定的延迟后运行命令,或者定期执行命令, 比 Timer更加灵活,功能更加强大。 ### ThreadPoolExecutor ThreadPoolExecutor 使用 Executors来创建,提供了4种类型的ThreadPoolExectuor, 分别是 newFixedThreadPool 、 newSingleThreadExecutor 、newScheduledThreadPool、 newCachedThreadPool. - 构造函数 ``` java /** * Creates a new {@code ThreadPoolExecutor} with the given initial * parameters. * * @param corePoolSize the number of threads to keep in the pool, even * if they are idle, unless {@code allowCoreThreadTimeOut} is set * @param maximumPoolSize the maximum number of threads to allow in the * pool * @param keepAliveTime when the number of threads is greater than * the core, this is the maximum time that excess idle threads * will wait for new tasks before terminating. * @param unit the time unit for the {@code keepAliveTime} argument * @param workQueue the queue to use for holding tasks before they are * executed. This queue will hold only the {@code Runnable} * tasks submitted by the {@code execute} method. * @param threadFactory the factory to use when the executor * creates a new thread * @param handler the handler to use when execution is blocked * because the thread bounds and queue capacities are reached * @throws IllegalArgumentException if one of the following holds:
* {@code corePoolSize < 0}
* {@code keepAliveTime < 0}
* {@code maximumPoolSize <= 0}
* {@code maximumPoolSize < corePoolSize} * @throws NullPointerException if {@code workQueue} * or {@code threadFactory} or {@code handler} is null */ public ThreadPoolExecutor(int corePoolSize, int maximumPoolSize, long keepAliveTime, TimeUnit unit, BlockingQueue workQueue, ThreadFactory threadFactory, RejectedExecutionHandler handler) ``` **参数说明:** corePoolSize:核心线程数,如果运行的线程少于corePoolSize,则创建新线程来执行新任务,即使线程池中的其他线程是空闲的 maximumPoolSize:最大线程数,可允许创建的线程数,corePoolSize和maximumPoolSize设置的边界自动调整池大小: corePoolSize <运行的线程数< maximumPoolSize:仅当队列满时才创建新线程 corePoolSize=运行的线程数= maximumPoolSize:创建固定大小的线程池 keepAliveTime:如果线程数多于corePoolSize,则这些多余的线程的空闲时间超过keepAliveTime时将被终止 unit:keepAliveTime参数的时间单位 workQueue:保存任务的阻塞队列,与线程池的大小有关: 当运行的线程数少于corePoolSize时,在有新任务时直接创建新线程来执行任务而无需再进队列 当运行的线程数等于或多于corePoolSize,在有新任务添加时则选加入队列,不直接创建线程 当队列满时,在有新任务时就创建新线程 threadFactory:使用ThreadFactory创建新线程,默认使用defaultThreadFactory创建线程 handle:定义处理被拒绝任务的策略,默认使用ThreadPoolExecutor.AbortPolicy,任务被拒绝时将抛出RejectExecutorException ### newFixedThreadPool 创建可重用且固定线程数的线程池,如果线程池中的所有线程都处于活动状态,此时再提交任务就在队列中等待,直到有可用线程;如果线程池中的某个线程由于异常而结束时,线程池就会再补充一条新线程。 ``` java public static ExecutorService newFixedThreadPool(int nThreads) { return new ThreadPoolExecutor(nThreads, nThreads, 0L, TimeUnit.MILLISECONDS, //使用一个基于FIFO排序的阻塞队列,在所有corePoolSize线程都忙时新任务将在队列中等待 new LinkedBlockingQueue()); } ``` ### newSingleThreadExecutor 创建一个单线程的Executor,如果该线程因为异常而结束就新建一条线程来继续执行后续的任务 ``` java public static ExecutorService newSingleThreadExecutor() { return new FinalizableDelegatedExecutorService //corePoolSize和maximumPoolSize都等于,表示固定线程池大小为1 (new ThreadPoolExecutor(1, 1, 0L, TimeUnit.MILLISECONDS, new LinkedBlockingQueue())); } ``` ### newScheduledThreadPool 创建一个可延迟执行或定期执行的线程池 ``` java /** * Creates a new {@code ScheduledThreadPoolExecutor} with the * given core pool size. * * @param corePoolSize the number of threads to keep in the pool, even * if they are idle, unless {@code allowCoreThreadTimeOut} is set * @throws IllegalArgumentException if {@code corePoolSize < 0} */ public ScheduledThreadPoolExecutor(int corePoolSize) { super(corePoolSize, Integer.MAX_VALUE, DEFAULT_KEEPALIVE_MILLIS, MILLISECONDS, new DelayedWorkQueue()); } ``` 使用 scheduledThread 来模拟心跳: ``` java public class HeartBeat { public static void main(String[] args) { ScheduledExecutorService executor = Executors.newScheduledThreadPool(5); Runnable task = new Runnable() { public void run() { System.out.println("HeartBeat........................."); } }; executor.scheduleAtFixedRate(task,5,3, TimeUnit.SECONDS); //5秒后第一次执行,之后每隔3秒执行一次 } } ``` ### newCachedThreadPool 创建可缓存的线程池,如果线程池中的线程在60秒未被使用就将被移除,在执行新的任务时,当线程池中有之前创建的可用线程就重用可用线程,否则就新建一条线程 ``` java public static ExecutorService newCachedThreadPool() { return new ThreadPoolExecutor(0, Integer.MAX_VALUE, 60L, TimeUnit.SECONDS, //使用同步队列,将任务直接提交给线程 new SynchronousQueue()); } ``` 例子: ``` java public class ThreadPoolTest { public static void main(String[] args) throws InterruptedException { ExecutorService threadPool = Executors.newCachedThreadPool();//线程池里面的线程数会动态变化,并可在线程线被移除前重用 for (int i = 1; i <= 3; i ++) { final int task = i; //10个任务 TimeUnit.SECONDS.sleep(1); threadPool.execute(new Runnable() { //接受一个Runnable实例 public void run() { System.out.println("线程名字: " + Thread.currentThread().getName() + " 任务名为: "+task); } }); } } } ``` 输出:(为每个任务新建一条线程,共创建了3条线程) 线程名字: pool-1-thread-1 任务名为: 1 线程名字: pool-1-thread-2 任务名为: 2 线程名字: pool-1-thread-3 任务名为: 3 去掉第6行的注释其输出如下:(始终重复利用一条线程,因为newCachedThreadPool能重用可用线程) 线程名字: pool-1-thread-1 任务名为: 1 线程名字: pool-1-thread-1 任务名为: 2 线程名字: pool-1-thread-1 任务名为: 3 ### Future 接口 Future 接口和实现了Future接口的FutureTask类用来表示异步计算的结果。当我们把Runnable 或者 Callable 接口的实现类提交给ThreadPoolExecutor时,Exector会返回给FutureTask对象 ### ScheduledThreadPoolExecutor ScheduledThreadPoolExecutor 继承自 ThreadPoolExecutor, 主要用来在给定的延迟后运行任务。 主要包含3个成员变量: - long: time ; 表示这个任务将要被执行的具体时间 - long: sequenceNumber; 表示这个任务被添加到SheduledThreadPoolExecutor 中的序号 - long:period; 表示任务执行的间隔周期 该类采用了DelyQueue,封装了一个优先队列,该队列会对队列中的SheduledFutureTask 进行排序。time小的会排在前面,如果time相同,则会比较sequenceNumber, 就是说如果两个任务的执行时间相同,谁先提交就谁先执行 # ThreadLocal 变量值的共享可以采用public static 的类变量,但是在多线程情况下,static 类变量显然不能满足多线程的读写,因此采用ThreadLocal 变量来存储多线程下的变量的副本。 ``` java /* * Copyright (c) 2018. Xiong Raorao. All rights reserved. * Project Name: book-notes * File Name: Test.java * Date: 18-7-25 下午5:32 * Author: Xiong Raorao */ package com.raorao.java.thread; /** * . * * @author Xiong Raorao * @since 2018-07-25-17:32 */ public class ThreadLocalTest { private static ThreadLocal local = new ThreadLocal<>(); public static void main(String[] args) throws InterruptedException { Thread t1 = new Thread(() -> { System.out.println(" I am t1"); local.set(1); try { Thread.sleep(2000); System.out.println("t1 value: " + local.get()); } catch (InterruptedException e) { e.printStackTrace(); } }); Thread.sleep(2000); Thread t2 = new Thread(() -> { System.out.println("I am t2"); System.out.println("before set , I get " + local.get()); try { Thread.sleep(2000); local.set(2); System.out.println("set after 2 s, I get " + local.get()); } catch (InterruptedException e) { e.printStackTrace(); } }); t2.start(); t1.start();// 无论怎么更换两个线程的启动顺序,得到的值是不一样的 } } ``` # Lock 除了使用synchronized 关键字加锁同步之外,也可以实现Lock 来自定义同步过程。 ## Synchronized jvm提供的一种互斥同步锁的方式 synchronized 可以作用于代码块,方法,类方法,类等,锁加载的 ## ReentrantLock ``` java public class LockExample { private Lock lock = new ReentrantLock(); public void func() { lock.lock(); try { for (int i = 0; i < 10; i++) { System.out.print(i + " "); } } finally { lock.unlock(); // 确保释放锁,从而避免发生死锁。 } } public static void main(String[] args) { LockExample lockExample = new LockExample(); ExecutorService executorService = Executors.newCachedThreadPool(); executorService.execute(() -> lockExample.func()); executorService.execute(() -> lockExample.func()); } } ``` 输出: 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 **synchronized 和 ReentrantLock的比较:** 1. 锁的实现 synchronized 是 JVM 实现的,而 ReentrantLock 是 JDK 实现的。 2. 性能 新版本 Java 对 synchronized 进行了很多优化,例如自旋锁等,synchronized 与 ReentrantLock 大致相同。 3. 等待可中断 当持有锁的线程长期不释放锁的时候,正在等待的线程可以选择放弃等待,改为处理其他事情。 ReentrantLock 可中断,而 synchronized 不行。 4. 公平锁 公平锁是指多个线程在等待同一个锁时,必须按照申请锁的时间顺序来依次获得锁。 synchronized 中的锁是非公平的,ReentrantLock 默认情况下也是非公平的,但是也可以是公平的。 5. 锁绑定多个条件 一个 ReentrantLock 可以同时绑定多个 Condition 对象。 ### ReentranceLock 几个特殊的方法 getHoldCount(): 查询当前线程保持此锁的个数 getQueueLength(): 返回正在等待获取次锁定的估计线程数。比如有5个线程,其中1个线程执行await()方法,调用该方法就返回4 getWaitQueueLength(): 返回等待与此锁定相关的给定条件Condition的线程估计数。 hasQueuedThread(Thread t): 查询指定线程是否正在等待获取此锁定 hasQueuedThreads(): 查询是否有线程正在等待获取此锁定 hasWaiters(Condition condition): 查询是否有线程正在等待与次锁定有关的condition条件 ## ReentranceReadWriteLock ReentranceLock 是完全互斥锁,同一时间,只有同一个线程在执行ReentrantLock.lock()后面的任务,虽然安全,但是效率低下。 ReentranceReadWriteLock(读写锁),读锁是共享锁,多个读锁之间不互斥,读锁和写锁之间互斥,写锁和写锁之间互斥。 ``` java package com.raorao.java.thread; import java.util.concurrent.locks.ReentrantReadWriteLock; /** * 读写锁测试. * * @author Xiong Raorao * @since 2018-08-06-11:48 */ public class ReentrantReadWriteLockTest { private ReentrantReadWriteLock lock = new ReentrantReadWriteLock(); public void read(){ lock.readLock().lock(); // 读锁 System.out.println("获得读锁 " + Thread.currentThread().getName() + " " + System.currentTimeMillis()); try { Thread.sleep(2000); } catch (InterruptedException e) { e.printStackTrace(); }finally { lock.readLock().unlock(); } } public void write(){ lock.writeLock().lock(); // 写锁 System.out.println("获得写锁 " + Thread.currentThread().getName() + " " + System.currentTimeMillis()); try { Thread.sleep(2000); } catch (InterruptedException e) { e.printStackTrace(); }finally { lock.writeLock().unlock(); } } public static void main(String[] args) { // 1. 读读共享, A 和 B 同时获得锁 ReentrantReadWriteLockTest test = new ReentrantReadWriteLockTest(); Thread t1 = new Thread(()-> { Thread.currentThread().setName("A"); test.read(); }); Thread t2 = new Thread(()-> { Thread.currentThread().setName("B"); test.read(); }); t1.start(); t2.start(); // 2. 写写互斥, D线程比C线程落后两秒执行 t1 = new Thread(()->{ Thread.currentThread().setName("C"); test.write(); }); t2 = new Thread(()->{ Thread.currentThread().setName("D"); test.write(); }); t1.start(); t2.start(); } } ``` 读写和写读两个锁也是互斥的,这里就不测试了。 ## condition condition 可以用于实现线程wait 和 notify,主要的方法有await()、signal() 和 signalAll() 方法,对应Object 类的 wait(), notify() 和notifyAll()方法,区别是,**前者只会通知持有锁的在等待的对象,后者则是对所有等待的线程通知,效率低下** ``` java package com.raorao.java.thread; import java.util.concurrent.locks.Condition; import java.util.concurrent.locks.Lock; import java.util.concurrent.locks.ReentrantLock; /** * 可重入锁测试. * * @author Xiong Raorao * @since 2018-08-06-10:27 */ public class ReentrantLockTest { private Lock lock = new ReentrantLock(); private Condition conditionA = lock.newCondition(); private Condition conditionB = lock.newCondition(); public static void main(String[] args) throws InterruptedException { ReentrantLockTest test = new ReentrantLockTest(); new Thread(() -> test.testLock()).start(); new Thread(() -> test.testLock()).start(); Thread t = new Thread(() -> test.awaitA()); t.start(); Thread.sleep(2000); test.signalA(); } public void awaitA() { lock.lock(); try { System.out.println("before awaitA at " + System.currentTimeMillis()); conditionA.await(); // 在此之前必须获得锁,不然报错illegalMonitorStateException 错误 System.out.println("after awaitA at " + System.currentTimeMillis()); } catch (InterruptedException e) { e.printStackTrace(); } finally { lock.unlock(); System.out.println(" 释放锁 awaitA "); } } public void signalA() { lock.lock(); try { System.out.println("signalA at " + System.currentTimeMillis()); conditionA.signal(); // 在此之前必须获得锁,不然报错illegalMonitorStateException 错误 System.out.println("signalA over at " + System.currentTimeMillis()); } finally { lock.unlock(); System.out.println(" 释放锁 signalA "); } } public void testLock() { lock.lock(); for (int i = 0; i < 5; i++) { System.out.print(i + " "); } System.out.println(); lock.unlock(); } } ``` 上面的程序对应的是利用Condition的进行等待和通知。 ## 公平锁和非公平锁 公平锁:线程获取锁的顺序使按照线程加锁的顺序来分配的,满足FIFO 非公平锁:等待线程抢占获取锁,也有可能造成某个线程一直获取不到锁 ReentrantLock 构造函数输入可以设置是否是公平锁,默认非公平锁。 # Timer Timer 定时器,主要负责计划任务的功能,也就是在指定的时间开始执行某一个任务。 ## shedule(TimerTask task, Date date) ``` java package com.raorao.java.thread; import java.text.ParseException; import java.text.SimpleDateFormat; import java.util.Date; import java.util.Timer; import java.util.TimerTask; /** * 定时器. * * @author Xiong Raorao * @since 2018-08-06-13:07 */ public class TimerTest { private static Timer timer = new Timer(); static class MyTask extends TimerTask{ @Override public void run() { System.out.println("运行时间: " + new Date()); } } public static void main(String[] args) { MyTask task1 = new MyTask(); try { Date taskDate = new SimpleDateFormat("yyyy-MM-dd HH:mm:ss").parse("2018-08-06 13:15:00"); System.out.println("执行时间: " + taskDate.toLocaleString() + ",当前时间" + new Date().toLocaleString()); timer.schedule(task1, taskDate); } catch (ParseException e) { e.printStackTrace(); } } } ``` 输出: 执行时间: 2018-8-6 13:15:00,当前时间2018-8-6 13:14:27 运行时间: Mon Aug 06 13:15:00 CST 2018 如果任务执行时间比当前时间晚,则到了计划时间执行,否则立即执行。 ## shedule 周期性执行 函数: shedule(TimeTask task, Date firstTime, long period) 表示在指定的日期之后,按照指定的时间间隔(period)周期性的无休止的执行某一任务。 **同样满足如果是未来的任务,到计划时间执行,否则立即执行** ## sheduleAtFixedRate 该方法和shedule方法的区别在于任务不延迟的情况。 shedule: 如果执行任务的时间没有被延迟,那么下一次任务的执行时间参考的是上一次任务的“开始”时间计算。 sheduleAtFixedRate: 如果执行任务的时间没有被延迟,那么下一次任务的执行时间参考的是上一次任务的“结束”时间计算。 # Concurrent 容器 ## BlockingQueue ![](img/TIM截图20180806153217.jpg) BlockingQueue 是一个阻塞接口,定义了阻塞队列的行为。 - boolean add(E e): 对尾插入元素,成功返回true; - boolean offer(E e): 队尾插入元素,成功返回true; 和 add 区别在于,如果超过队列容量,add 会抛出 IllegalStateException 异常 - void put(E e): 队尾插入元素,如果在线程等待的时候发生线程中断,抛出异常。 - boolean offer(E e, long timeout, TimeUnit unit): 超时放弃,线程等待的时候如果发生中断信号,也会抛出中断异常。 - E take(): 弹出队头元素,线程等待的时候如果发生中断信号,也会抛出中断异常。 - E remove(): 弹出队头元素, 如果为空,抛出NoSuchElementException; - E poll(): 弹出队头元素,如果为空,返回null - E poll(long timeout, TimeUnit unit): 超时放弃,线程等待的时候如果发生中断信号,抛出异常。 - E element(): 仅仅返回对头元素, 如果为空,抛出NoSuchElementException; - E peek(): 仅仅返回队头元素,如果为空,返回null - int remainingCapacity(): 返回理想情况下,可以直接入队不用阻塞的元素个数 ## DelayQueue ![](img/TIM截图20180806160547.jpg) 无界的阻塞队列(BlockingQueue), 用于防止实现了Delayed接口的对象,其中的对象只能在到期时才能从对队列中取走。队列本身是有序的, 即对头对象的延迟到期的时间最长的Delayed元素。 为了具有调用行为,存放到DelayDeque的元素必须继承Delayed接口。Delayed接口使对象成为延迟对象,它使存放在DelayQueue类中的对象具有了激活日期。该接口强制执行下列两个方法。 CompareTo(Delayed o):Delayed接口继承了Comparable接口,因此有了这个方法。 getDelay(TimeUnit unit):这个方法返回到激活日期的剩余时间,时间单位由单位参数指定。 ``` java public class DelayEvent implements Delayed { private Date startDate; public DelayEvent(Date startDate) { super(); this.startDate = startDate; } @Override public int compareTo(Delayed o) { long result = this.getDelay(TimeUnit.NANOSECONDS) - o.getDelay(TimeUnit.NANOSECONDS); if (result < 0) { return -1; } else if (result > 0) { return 1; } else { return 0; } } @Override public long getDelay(TimeUnit unit) { Date now = new Date(); long diff = startDate.getTime() - now.getTime(); return unit.convert(diff, TimeUnit.MILLISECONDS); } } public class DelayTask implements Runnable { private int id; private DelayQueue queue; public DelayTask(int id, DelayQueue queue) { super(); this.id = id; this.queue = queue; } @Override public void run() { Date now = new Date(); Date delay = new Date(); delay.setTime(now.getTime() + id * 1000); // 根据id的不同,延迟的时间不同 System.out.println("Thread " + id + " " + delay); for (int i = 0; i < 100; i++) { DelayEvent delayEvent = new DelayEvent(delay); queue.add(delayEvent); } } } public class DelayDequeMain { public static void main(String[] args) throws Exception { DelayQueue queue = new DelayQueue(); Thread threads[] = new Thread[5]; for (int i = 0; i < threads.length; i++) { DelayTask task = new DelayTask(i + 1, queue); threads[i] = new Thread(task); } for (int i = 0; i < threads.length; i++) { threads[i].start(); } for (int i = 0; i < threads.length; i++) { try { threads[i].join(); } catch (InterruptedException e) { e.printStackTrace(); } } do { int counter = 0; DelayEvent delayEvent; do { delayEvent = queue.poll(); if (delayEvent != null) { counter++; } } while (delayEvent != null); System.out.println("At " + new Date() + " you have read " + counter+ " event"); TimeUnit.MILLISECONDS.sleep(500); } while (queue.size() > 0); } } ``` ## PriorityBlockingQueue ![](img/TIM截图20180806160740.jpg) 阻塞的优先队列。 ## ArrayBlockingQueue 和 LinkedBlockingQueue ![](img/TIM截图20180806162223.jpg) ![](img/TIM截图20180806162336.jpg) FIFO 阻塞队列, 前者采用固定数组长度的数组实现队列(初始化需指定队列长度),后者采用链表实现。 ## ConcurrentHashMap ![](img/TIM截图20180806163031.jpg) ConcurrentHashMap 默认容量为16, 最大容量2^30,默认并发度16,负载因子0.75。当散列桶的元素个数超过8的时候,将链表改为红黑树(jdk1.8)。 ConcurrentHashMap 相较于HashMap,采用了分段锁(Segment, 继承自 ReentrantLock)的方式保证多线程安全(JDK1.7)。 在JDK1.8 中, CAS 操作来支持更高的并发度,在 CAS 操作失败时使用内置锁 synchronized, ## ConcurrentLinkedDeque 和 ConcurrentLinkedQueue ![](img/TIM截图20180806164620.jpg) ![](img/TIM截图20180806164709.jpg) ConcurrentLinkedDeque: 线程安全的链表实现的双端队列。 ConcurrentLinkedQueque: 线程安全的链表实现的队列。 ## Deque Deque 定义一个双端队列的接口,可以在两段进行插入和弹出, 方法如下: 修饰符和返回值 | 方法名 | 描述 --- | --- | --- void | push(E) |向队列头部插入一个元素,失败时抛出异常 void | addFirst(E) |向队列头部插入一个元素,失败时抛出异常 void | addLast(E) |向队列尾部插入一个元素,失败时抛出异常 boolean | offerFirst(E)|向队列头部加入一个元素,失败时返回false boolean | offerLast(E)|向队列尾部加入一个元素,失败时返回false E | getFirst() | 获取队列头部元素,队列为空时抛出异常 E | getLast() | 获取队列尾部元素,队列为空时抛出异常 E | peekFirst() | 获取队列头部元素,队列为空时返回null E | peekLast() | 获取队列尾部元素,队列为空时返回null boolean | removeFirstOccurrence(Object) | 删除第一次出现的指定元素,不存在时返回false boolean | removeLastOccurrence(Object) | 删除最后一次出现的指定元素,不存在时返回false E | pop() | 弹出队列头部元素,队列为空时抛出异常 E | removeFirst() | 弹出队列头部元素,队列为空时抛出异常 E | removeLast() | 弹出队列尾部元素,队列为空时抛出异常 E | pollFirst() | 弹出队列头部元素,队列为空时返回null E | pollLast() | 弹出队列尾部元素,队列为空时返回null Iterator | descendingIterator() | 返回队列反向迭代器 ### LinkedList ![](img/TIM截图20180806171115.jpg) LinkedList: 链表实现的双端队列 ### ArrayDeque ![](img/TIM截图20180806171310.jpg) ArrayDeque: 数组实现的双端队列,默认队列长度为16,队列满了就直接扩充一倍(double) ## Vector Vector 是一个线程安全的动态数组,内部采用数组实现,和ArrayList的区别在于,ArrayList的增长速度是50%,而 Vector 的增长速度为100% # 线程间通信 1. 同步方法 synchronized或者ReentrantLock 2. while 轮询 3. wait/notify机制 4. 管道通信 PipedInputStream 5. 共享内存(共享对象) 6. volitale、原子类 # 参考文档 - [java并发编程--Executor框架](https://www.cnblogs.com/MOBIN/p/5436482.html)
